Main Applications and Features

• Coal Field Digital      Integrated Logging

• Hydrological Engineering      Digital Integrated Logging

• Solid Metal Ore Digital      Integrated Logging

• Other Minerals Digital      Integrated Logging

• External Laptop (Desktop      PC)

• For upward logging, also      for downward logging

• Receive digital signal,      analog signal

• 8 taps of power supply      current, Optional

• Automatic sampling as per      depth interval, sampling interval arbitrarily

• Indoor simulation      logging, repeatability observation of instruments and probes

• Membrane panel,      attractive and durable

 Technical Specifications

• 12bit A/D Conversion, Program-Controlled Magnification K=0.5~128

• Counting Channel: f≤500KHz

• Digital Signal Transmission Frequency: 9600bit/s

• Power Supply Cycle: 400ms

• Current: 2mA~500 mA Optional

• Signal Input Range: ≤±10V

• Continuous Working Time: ≤24 hr

• Power Consumption: ＜200W

• Volume: 420×260×210mm,

• Weight: ＜7Kg

• Working Temperature Range: -10℃~ +50℃

• Working Power Supply: AC220V±10% 50Hz ±5%

• Logging Speed: 0~30 m/min Adjustable (as per sampling interval)

Logging Working Software System

• 12bit A/D Conversion, Program-Controlled Magnification

• ?Operation Environment: Windows98/2000/XP

• Sampling Interval: Arbitrary (1~25000px)
       Setting (25px, 50px, NaN)

• Maximum depth of one-time acquisition: 3000m (0.1m sampling interval)

• Depth automatic alignment of multi-parameters

• Superposition of multi-parameters up to 10

• Curve movement, anomaly removal, smoothing, inverted order, ,      segmentation, calculation, etc.

• Interpretation of profile input, automatic generation of rock stratum      name, thickness and baseplate depth

• Curve amplification and compression

• 5 types of curve depth ratio: 1∶50, 1∶100, 1∶200, 1∶500, 1∶1000

• Continuous drawing production in color or black-and-white effects

• Output graph maximum width: 415mm, length: 2310
